Tarter 200 Series Rotary Tiller
If you have gardening or food plot projects, the 200 Series 5′ Rotary Tiller quickly cultivates, aerates, and stirs up the soil to prep your land properly for seed or planting. Adjustable skid shoes allow for tilling depths up to 7″ after multiple passes, and the reversible tine rotation option breaks up the toughest soil. A cast iron top gearbox and formed steel side gearbox house forged and hardened steel gears.
With a heavy-duty slip clutch, there’s less worry about damaging the PTO if the implement jams on a rock or foreign object. If you do though the self-sharpening, heat-treated cutting tines are durable, yet replaceable.
The Tarter 200 Series 5′ Rotary Tiller is Cat 1 and Quick Hitch compatible, ideally suited to tractors 25-60 PTO HP.
Also available in 6’ and 7’ models.
SPECS
| Tractor PTO Horsepower | 25-50 |
| Hitch Type | Cat 1 |
| Working Width | 58.75 in. |
| Working Depth | 7 in. |
| Driveline | 540 RPM Slip Clutch Protection |
| Number of Flanges on Rotor | 7 |
| Number of Tines per Flange | 6 |
| Rotor Rotation | Reversible (FWD/ REV) |
| Rotor Shaft Speed | 211 rpm @ 540 rpm PTO |
| Skid Shoes | adjustable (0.4 in., 1.4 in.,2.4 in.) |
| Top Gearbox Construction | Cast Iron Housing, Hardened Steel Gears |
| Side Drive Construction | Formed Steel Housing, Hardened Steel Gears |
| Top Gearbox Lubrication | EP 80-90W gear oil |
| Side Drive Lubrication | EP 80-90W gear oil |
| Major Construction | 0.375 in. solid steel gearbox plate and endplates, 0.625 in. steel hitch frame |
| Part | RT205BL |
| Width | 64 in. |
| Approx. Weight | 638 lbs |
| Color | BLACK |
| Quick Hitch Compatible | Yes |
| Warranty | 1 Year |
Gearbox requires approximately 4 quarts of EP 80-90W gear oil (not included) and must be filled prior to operation.
